LG UH7F Series 65UH7F-B

  • Brightness(Typ.) : 700 cd/m²
  • Bezel : 9.9 mm (T/R/L), 14.4 mm (B)
  • Depth : 39.9 mm
  • Interface : HDMI(3)/DP/DVI-D/USB 2.0/ RS232C/ RJ45/ Audio/ IR
  • Built-in Speaker and Detachable Logo
  • 30º Tilting Installation

Description

PANEL

  • Screen Size
    65″
    Panel Technology
    IPS
  • Aspect Ratio
    16 : 9
    Native Resolution
    3,840 x 2,160 (UHD, RGB)
  • Brightness(Typ.,cd/m²)
    700
    Contrast Ratio
    1,100:1
  • Viewing Angle (H x V)
    178 x 178
    Response Time
    8ms (G to G)
  • Surface Treatment (Haze)
    Haze 3%
    Life Time (Typ.)
    50,000 Hrs
  • Operation Hours
    24 Hrs
    Orientation
    Portrait & Landscape

CONNECTIVITY

  • Input
    HDMI (3), DP, DVI-D, Audio, USB 2.0
    Output
    DP, Audio (Off/Fixed/Variable)
  • External Control
    RS232C In/out, RJ45 (LAN) In, IR In

MECHANICAL SPECIFICATION

  • Bezel Color
    Black
    Bezel Width
    9.9mm(T/R/L), 14.4mm(B)
  • Monitor Dimension (W × H × D)
    1,453.3mm x 844mm x 39.9mm
    Weight (Head)
    28.2 kg
  • Carton Dimensions (W × H × D)
    1,600mm x 1,095mm x175mm
    Packed Weight
    35.0 kg
  • Handle
    No
    VESA™ Standard Mount Interface
    300 x 300

SPECIAL FEATURE

  • Tilt (Facedown)
    Max. 30º *In conditions within 30ºC temperature, 50% humidity
    IP Rating
    IP5x

ENVIRONMENT CONDITIONS

  • Operation Temperature
    0°C to 40°C
    Operation Humidity
    10 % to 80 %

POWER

  • Power Supply
    100-240V~, 50/60Hz
    Power Type
    Built-In Power

POWER CONSUMPTION

  • Typ. / Max.
    130W / 180W
    Smart Energy Saving
    100W

CERTIFICATION

  • Safety
    CB / NRTL
    EMC
    FCC Class “A” / CE / KC

MEDIA PLAYER COMPATIBILITY

  • OPS type compatible
    Yes

SOFTWARE COMPATIBILITY

  • Content Management Software
    SuperSign CMS
    Control and Monitoring Software
    SuperSign Control/Control+
  • Signage365Care
    Yes

ACCESSORY

  • Basic
    Remote Controller, Power Cord, QSG, HDMI Cable, Regulation Book, Phone to RS232C Gender
    Optional
    Stand(ST-653T), Media Player, Wall Bracket(LSW350B), VESA Adapter(AM-B330S), OPS Kit (KT-OPSF)

GENERAL

  • Region
    Global
