LG SH7DB Series 55SH7DB-M

  • Brightness(Typ.): 700 cd/m²
  • Bezel : Top/Left/Right/Bottom 7.4mm
  • Depth : 31.7mm
  • DP/HDMI/DVI/RGB/RS232C/RJ45/IR (DP1.2 daisy-chain)

Description

PANEL

  • Screen Size
    54.64″ (1387.80mm) diagonal
    Resolution
    1,920 x 1,080 (FHD)
  • Brightness (Module, Typ., cd/m²)
    700

CONNECTIVITY – INTPUT

  • HDMI
    Yes (1)
    DP
    Yes (1)
  • DVI
    Yes (1)
    Analog (RGB)
    Yes (1)
  • Audio
    Yes (1)
    External Control (RS232C(Phone Jack Type))
    Yes (1)
  • External Control (RJ45)
    Yes (1)
    External Control (IR receiver)
    Yes (1)
  • External Control (Pixel Sensor(Optional))
    Yes
    USB
    Yes (1)

CONNECTIVITY – OUTPUT

  • DP Out
    Yes
    Audio Out
    Yes
  • Externel Speaker Out
    Yes (1, L/R)
    External Control (RS232C OUT)
    Yes (1)

PHYSICAL SPECIFICATION

  • Bezel Width
    7.4mm (T/L/R/U even)
    Monitor Dimension (W x H x D)
    123.0cm X 71.4cm X 3.2cm
  • Weight (Head)
    27.0kg
    VESA™ Standard Mount Interface
    400mm x 400mm

STANDARD (CERTIFICATION)

  • ErP / Energy Star
    Yes (EU Only) / N/A

MEDIA PLAYER COMPATIBILITY

  • OPS type compatible
    Yes
    External Media player Attatchable
    Yes (MP500/MP700)

SOFTWARE COMPATIBILITY

  • SuperSign-w lite
    Yes
    SuperSign-c
    Yes

ACCESSORY

  • Basic
    Remote Controller (include battery 2ea), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, IR Receiver
    Optional
    SP-2100 (External Speaker), ST-200T, LSW440S, AN-WF500 (WiFi USB Dongle), KT-OPSA (OPS Kits), KT-SP0 (Pixel Sensor)

GENERAL

  • Region
    Global
