Description
以卓越的 4K* 畫質與高效的 IP 製播工作流程，捕捉每一個視角
多功能的 SRG-X120 遙控 PTZ 攝影機，適用於從教室、會議空間到醫療環境等廣泛的應用場景。
本攝影機採用 1/2.5 型 Exmor R CMOS 感光元件，可拍攝高達 4K* 解析度的影像，具備出色的靈敏度、極低的雜訊以及豐富自然的色彩重現。搭配內建的高解析度 12 倍光學變焦鏡頭，提供約 70° 的寬廣廣角覆蓋範圍，可捕捉每一個視角。
在預設位調用期間的高速移動能捕捉講者的每一個動作，而轉換期間的畫面凍結功能可確保觀眾不會受到攝影機快速移動的干擾。PTZ Motion Sync*** 功能可將獨立的平移、俯仰與變焦動作順暢融合，實現無縫、專業的轉場效果。
支援 NDI®|HX 進一步強化了基於 IP 的高效現場製作能力，可與其他支援 NDI® 的網路設備進行靈活配置。
亦可透過網頁瀏覽器遠端檢視影像，支援 RTSP（即時串流協定）、RTMP（即時訊息傳遞協定）與 SRT安全可靠傳輸），確保在 IP 網路上流暢、穩定地串流視訊及音訊（來自選購的麥克風，需另購）。
安裝與設定簡便，全新的 Picture Setting File**** 功能可透過筆記型電腦或 PC 的網頁介面，將相同的設定套用至多台攝影機。
* 搭配清晰影像變焦與遠攝轉換模式
*** 需韌體版本 V3.00
**** 需韌體版本 V2.00
注意 1：本產品包含預先安裝的軟體，需購買授權金鑰才能啟用部分功能。
注意 2：使用 RM-IP500 時，韌體需更新至 V2.10；使用 RM-IP10 時，韌體需更新至 V2.17。
功能特點
- 即使在低光源下也有出色的影像：高靈敏度的 1/2.5 型 Exmor R™ 感光元件，即使在昏暗環境中也能捕捉低雜訊的高品質影像。
- 4K 升級選項：可透過選購授權升級至 4K 拍攝。
- 寬廣視角：水平視角約 70°，搭配高達 12 倍的變焦能力，可完整覆蓋會議與講堂中的整個場景。
- 適用於課堂錄製：將本攝影機與基於 AI 的 REA-C1000 Edge Analytics 邊緣分析裝置搭配使用，可流暢追蹤講者的移動，並自動生成講者的去背特寫影像。
- 高速移動與畫面凍結預設：在預設位調用期間，以最高 300°/s 的平移與俯仰速度精準捕捉講者的動作。畫面凍結預設功能可在攝影機移動至新預設位時維持穩定的影像，避免觀眾因不舒適的轉場而感到困擾。
- 流暢的平移、俯仰、變焦：PTZ Motion Sync 功能* 可將獨立的平移、俯仰與變焦動作順暢融合，實現無縫、專業的轉場效果。 * 需韌體版本 V2.00。
- 更簡便的安裝，更低的成本：單一網路線即可承載攝影機電源、視訊輸出與控制訊號，簡化安裝並降低佈線成本。
- 支援 NDI®*|HX：透過選購授權支援 NDI®|HX，可實現具成本效益的校園攝影棚系統整合，並與其他支援 NDI® 的網路設備進行靈活配置。 * NDI® 是 Vizrt NDI AB 的註冊商標。
- 靈活高效的 IP 製播：除 RTSP 外，亦支援 RTMP(S)* 與 SRT*（安全可靠傳輸）。可將視訊直接從攝影機串流至線上串流服務，即使在不穩定的網路環境中，也能以更低延遲、更安全、更穩定的方式進行傳輸。 * 需韌體版本 V3.00。
- 快速、無憂的設定：全新的 Picture Setting File* 功能可將相同的攝影機設定套用至多台攝影機，實現快速設定。 * 需韌體版本 V2.00。
Capture every point of view with excellent 4K* picture quality and efficient IP production workflow
The versatile SRG-X120 remotely controlled PTZ camera is ideal for a wide range of applications – from classrooms and meeting spaces and medical environments.
The camera’s 1/2.5-type Exmor R CMOS sensor captures up to 4K* resolution images with excellent sensitivity, very low noise and rich, natural colour reproduction. It’s complemented by the integrated high-resolution 12x zoom lens that offers an expansive approx. 70° wide angle coverage to capture every point of view.
High speed movement during preset recall captures the speaker’s every movement, while Picture Freeze during transitions ensures your audience isn’t disturbed by rapid camera movements. PTZ Motion Sync*** function allows smooth blending of separate pan, tilt and zoom movements for seamless, professional-looking transition.
Efficient IP-based live production is augmented with support for NDI®|HX allowing flexible configuration with other networked NDI®-enabled devices.
Images also can be reviewing remotely via a web browser, with support for RTSP (Real Time Streaming Protocol), RTMP*** (Real Time Messaging Protocol) and SRT*** (Secure Reliable Transport) ensuring smooth, stable streaming of video plus audio (from an optional microphone, available separately) over an IP network.
Installation and set-up is easy, with a new Picture Setting File**** allowing the same settings to be applied to multiple cameras through a web interface from a laptop or PC.
* NDI® is a registered trademark of Vizrt NDI AB
** With Clear Image Zoom and Tele Convert Mode
*** Requires firmware V3.00
**** Requires firmware V2.00
Note 1: This product contains pre-installed software and requires the purchase of licence keys to activate some functions.
Note 2: When using RM-IP500 firmware should be updated to V2.10 and for RM-IP10, firmware should be updated to V2.17.
Features
- Excellent images, even in low light: The sensitive 1/2.5-type Exmor R™ sensor captures high-quality images with very low noise, even in dimly-lit environments.
- 4K upgrade option: Upgrade to 4K shooting via optional license.
- Wide viewing angle: Cover the whole scene in meetings and lecture theatres with a horizontal viewing angle of approx. 70° and up to 12x zoom capability.
- Ideal for lecture capture: Use the camera in conjunction with the AI-based REA-C1000 Edge Analytics Appliance to smoothly track the speaker’s movements and automatically generate a cut-out image of the speaker.
- High speed movement and Picture Freeze Preset: Accurately capture the presenter’s movements with maximum 300°/s pan and tilt movement during preset recall. Picture Freeze Preset maintains a steady image while the camera moves to a new preset position – with no uncomfortable transitions for your audience.
- Smooth pan-tilt-zoom: PTZ Motion Sync function* allows smooth blending of separate pan, tilt and zoom movements for seamless, professional-looking transitions.
* Requires firmware V2.00. - Simpler installation, lower costs: A single network cable carries camera power, video output and control signals to simplify installation and reduce cabling costs.
- Support for NDI®*|HX: NDI®|HX compatibility (via optional license) enables cost-effective school studio system integration, allowing flexible configuration with other networked NDI®-enabled devices.
* NDI® is a registered trademark of Vizrt NDI AB - Flexible and efficient IP-based production: In addition to RTSP, RTMP(S)* and SRT* (Secure Reliable Transport) are supported. Video can be streamed directly from the camera to an online streaming service, and can also be transmitted more securely, with lower latency and more stably even in unstable network environments.
* Requires firmware V3.00. - Fast, fuss-free set-up: The new Picture Setting File* function can apply the same camera settings among multiple cameras for fast set-up.
* Requires firmware V2.00.
