Panasonic PT-MZ10K Installation type LCD projector

  • 1″ 16:10 LCD panel
  • Brightness: 10000 lumens; Contrast ratio: 3000000:1
  • Resolution: 1920 x 1200 (WUXGA)
  • Lens shift function (vertical: ±60%, horizontal: ±20%, powered)
  • Wide selection of optional lens
  • 4K signal input compatible
  • Optional digital interface box ET-YFB100G or ET-YFB200G
  • Laser diode source
  • Digital Link transmits digital signals up to 100 m with a single cable

Description

  • Brightness: 10000 lumens
  • Resolution: 1920 x 1200 (WUXGA)
  • Lens shift function (vertical: ±60%, horizontal: ±20%, powered)
General
Panel Type 1″ LCD panel x 3
Lamp N.A.
Brightness 10,000 lumens
Lens optional
Contrast (Full on / Full off) 3,000,000:1
Resolution (Native / maximum) WUXGA
Screen Size 80″ – 500″
Lens Shift Vertical ±60%, horizontal ±20%
Keystone Correction Range Vertical ±40° or horizontal ±15° (Using ET-EMS600 lens. For others, please refer to catalogO
Weight approximately 22.3kg
Dimensions (W x H x D) 650 x 211 x 440 mm
Power Consumption 640W
Terminals SDI In (BNC x1: 3G/HD-SDI)
HDMI In (19-pin x1)
DVI-D In (24-pin x1)
RGB In (BNC x5)
Serial/Sync In (D-sub 9-pin x1)
Serial /Sync out (D-sub 9-pin x1)
Remote 1 In (D-sub 9-pin x1)
Remote 2 In (M3 x1))
Remote 2 out (M3 x1)
Digital Link (RJ-45 x1)
LAN (RJ-45 x1)
DC out (USB x1)
Optional Accessories ET-PKE301B (Bracket assembly)
ET-PKD120H (High ceiling mount bracket)
ET-PKD120S (Low ceiling mount bracket)
ET-RFM100 (Replacement filter unit
ET-YFB200 (Digital Link Switcher)
ET-UK20 (Geometry Manager Pro)
ET-NUK10 (NFC Upgrade kit)
Optional Lens Zoom lens ET-EMW200 (0.48-0.55:1)
ET-EMW300 (0.55-0.69:1)
ET-EMW400 (0.69-0.95:1)
ET-EMW500 (0.95-1.36:1)
ET-EMS600 (1.35-2.10:1)
ET-EMT700 (2.10-4.14:1)
ET-EMT800 (4.14-7.40:1)
Standard Accessories Software CD-ROM
Wireless / wired remote control & batteries
Power cord
