- XLS High Performance, Lightweight Class D amp weighs less than 11 lbs.
- Integrated PureBand™ Crossover System for better performance and control
- Peakx™ Limiters provide maximum output while protecting your speakers
- XLR, 1/4″, RCA inputs provide outstanding flexibility
- Efficient forced-
air fans prevent excessive thermal buildup
- Electronically balanced XLR inputs; touchproof binding post and Speakon® outputs
- Precision detented level controls, power switch, power LED, and six LEDs which indicate signal, clip and fault for each channel
XLS Series with Integrated DriveCore™ Technology
The XLS Series of power amplifiers from Crown define the standard for live sound systems with unmatched performance, technology, and affordability.
Every XLS Series amplifier is backed by Crown’s unequaled Three-
With over five decades of experience designing and building rock-
Integrated DriveCore™ Technology
Class D amplifiers are notable for extraordinarily high efficiency and being well suited for driving difficult reactive loads such as subwoofers. However, their performance can suffer impaired performance on marginal and unstable AC line supplies.
To overcome this obstacle, Crown engineers developed DriveCore™ Technology – a proprietary hybrid analog-
DriveCore™ Technology provides an extremely wide-
In addition, DriveCore™ Technology’s patented feedback and PWM modulation circuits enable fast recovery on peak transients, accurate reproduction of low-
This advanced power supply is highly efficient and optimized for maximum power transfer from the AC line through the Class D output stage to the loudspeakers. A benefit to this is substantial weight reduction when compared to older 60Hz transformer-
PureBand™ Crossover System
The PureBand™ Crossover System in the XLS Series adds an enormous amount of flexibility and performance to any system. With this system, the crossover frequency is completely variable allowing the choice of any crossover point between 50Hz and 3kHz on 1/12 octave centers. The use of 4th order Linkwitz-
Crossover Mode (CH1=LPF, CH2=HPF) – When chosen, this mode enables a LowPass Filter on Channel 1 and a HighPass Filter on Channel 2 at the frequency chosen.
LowPass Mode (CH1=LPF, CH2=LPF) – When chosen, this mode enables a LowPass Filter on both Channel 1 and Channel 1 at the frequency chosen.
HighPass Mode (CH1=HPF, CH2=HPF) – When chosen, this mode enables a HighPass Filter on both Channel 1 and Channel 2 at the frequency chosen.
Bridge Mode (LPF or HPF) – When the amplifier is put into Bridge-
All of the PureBand™ Crossover System settings can be fully configured quickly and easily from the front panel using the intuitive LCD interface.
Peakx™ limiters provide the ultimate in performance and protection for your entire system. This advanced algorithm was specifically developed and tuned to work with this amplifier and power-
